What Is THD in Audio Testing?
THD (Total Harmonic Distortion) can be defined as the degree of distortion that takes place within an audio signal in passing through a nonlinear system or device. Ideally, if the input is a sine-wave audio signal, then after the sine-wave signal passes through the audio device, the output should be the fundamental frequency. But this does not happen because of the nonlinear nature of the device.
In a situation where one has an input signal whose frequency is 1 kHz, one can get harmonics of 2 kHz, 3 kHz, 4 kHz, and so forth. In THD audio analysis, the interaction of the harmonics and the fundamental signal is taken into account. It is always presented as a percentage.
Why Does THD Matter?
A low THD implies that the audio device distorts the audio signal to a lower extent, while a high THD implies distortion of the audio signal, but it all depends on the equipment. THD test is important in:
- Amplifier evaluation
- Speaker evaluation
- Evaluation of audio devices
- Testing nonlinear circuits
- Verifying specifications of the manufacturers
- Quality control testing
Can Audio Analyzers Measure THD?
Yes, audio analyzers can be used to measure THD (total harmonic distortion). The audio analyzers analyze the unwanted harmonics present in the audio signal and determine the distortion percentage. Professional audio analyzers give reliable results and therefore are very useful for analyzing signal performance and audio fidelity in general.
How Does an Audio Analyzer Measure THD?
A distortion measurement unit usually consists of a signal generator and measuring system that compares the input test signal against the output of the system. The process is usually carried out by:
- Generation of a test signal sine wave by the analyzer.
- Passage of the test signal through the device under test.
- Collection of the output from the device under test by the analyzer.
- Isolation of the fundamental waveform from the harmonics.
- Calculation of the harmonic energy relative to the fundamental.
- Displaying the result in terms of THD percentage.
This process is the basic principle of THD measurement. There are special units that measure THD, which carry out most of this process automatically.
Audio Analyzer THD Measurement vs. Basic Oscilloscope Testing
The oscilloscope can give indications of waveform changes; however, it is not always the best choice for THD measurements. The audio analyzer is made especially for quantitative audio measurements. It can make audio distortion measurements. It can produce numerical readings that will be more easily comparable. The total harmonic distortion analyzer can also provide:
- THD
- THD+N
- Harmonic distortion levels individually
- SNR
- Frequency Response
- Amplitude
- Phase
- Intermodulation distortion
This makes the analyzer very helpful in professional audio measurements.
How Do You Choose a THD Analyzer?
When choosing a THD measuring equipment solution, the following needs to be taken into account:
| Specification | Why It Matters |
| Frequency range | Determines which audio frequencies can be tested |
| Residual THD | Indicates analyzer-generated distortion |
| Noise floor | Important for low-level measurements |
| Dynamic range | Supports demanding signal measurements |
| Input range | Determines compatible signal levels |
| Bandwidth | Affects harmonic analysis |
| Automation | Improves repeatability |
| Connectivity | Supports integration with test systems |
A good professional THD measuring solution must have adequate performance for the device under test.
THD Measurement in Professional Audio Equipment Testing
The use of THD is applied by manufacturers during research and development, quality control, and manufacturing processes. Some audio equipment that might be tested using the technique includes amplifiers, headphones, speakers, DACs, ADCs, mixers, receivers, among others.
The controlled THD test procedure enables the manufacturer to establish whether the product meets internal specifications and/or published specifications. For manufactured products, the test equipment could be incorporated into automated software.
How Accurate Is an Audio Analyzer for THD?
A calibrated analyzer can produce very accurate readings, but accuracy relies on the entire testing setup.
The distortion produced by the analyzer itself must be considerably lower than the distortion that is being measured. Calibration, cabling, signal strength, grounding, and test setup are also important factors.
In critical tests, engineers need to compare the analyzer's published THD accuracy and distortion specifications with what the device under test is expected to deliver.
What Are the Benefits of Using an Audio Analyzer?
The use of an analyzer to perform THD testing has some benefits:
- Quick automatic measurements
- Consistent readings
- Accurate harmonic measurement
- Numeric THD measurements
- Visualization in the frequency domain
- Multiple audio measurements by a single system
- Facilitates production testing
- Extensive documentation of performance
All this makes analyzers essential tools for development and production laboratories.
What Is a Battery Pack Simulator?
The battery pack simulator is a programmable tool that can mimic the electrical performance of a battery pack. Rather than linking a product to a real-life lithium-ion battery, the engineer can use the simulator to mimic various voltage and current levels. Modern battery simulators can simulate various states of the battery, which include:
- Voltage variation
- Behavior during charging and discharging
- Load variations
- State of charge (SOC)
- State of health (SOH)
- Dynamic currents
- Faults in batteries
- Regenerative energy state
This method enables controlled simulation of battery packs and ensures that products can be tested safely and repeatedly.
Can a Battery Pack Simulator Test Lithium-Ion Batteries?
Yes, the utilization of battery pack simulation is an effective method of testing lithium-ion batteries by using voltage, current, charging, discharging, load changes, and fault simulation. The simulator will help the engineer analyze the battery, battery management system, and the electronic components of the battery. Though the simulators do not fully substitute for all tests on batteries, they provide an accurate environment for development and validation.
How Does a Battery Pack Simulator Test Lithium-Ion Batteries?
The simulator does not generally put the chemical cells through tests that are the same as those for lab tests on the cells. Rather, it simulates what the expected electrical behavior should be for the lithium-ion battery. Some of the things an engineer might want to simulate include:
- A fully charged battery pack
- A partly discharged pack
- Fast-changing currents
- Charging state
- Low voltage state
- Over-current conditions
- Faulty batteries
- Electrical behavior due to temperature conditions
Using appropriate battery simulation software, an engineer can make a simulated battery model from actual or theoretical battery specifications.
Why Use Battery Simulation Instead of Real Cells?
| Factor | Real Lithium-Ion Pack | Battery Pack Simulator |
| Safety | Fire/thermal runaway risk | No hazardous chemistry involved |
| Repeatability | Cells degrade over time | Identical conditions every test |
| Speed | Aging takes weeks/months | Instant state changes |
| Fault testing | Destructive, one-time only | Safe, repeatable fault injection |
| Cost | Expensive to scrap damaged packs | Reusable test asset |
The above comparison is precisely why the use of software for battery simulation and battery testing system hardware is essential equipment in laboratories that develop electric cars, drones, grid storage, and consumer electronics.
Battery Pack Simulation vs. Physical Battery Testing
Battery pack modeling and simulation represent an alternative solution to some types of testing, but they cannot totally substitute for battery tests conducted in laboratories.
| Simulation | Physical Testing |
| Reproduces electrical behavior | Tests actual cells |
| Highly repeatable | Represents real-world cell variation |
| Fast parameter changes | Real chemical and thermal behavior |
| Useful for early development | Essential for final validation |
| Can test faults safely | Provides real battery evidence |
| Supports automated testing | Requires physical equipment |
The optimal development process usually entails both battery pack analysis and testing.
Conclusion
Audio analyzers help in measuring total harmonic distortion in an accurate and repeatable manner. In a similar fashion, a battery pack simulator can be used to simulate lithium-ion battery behavior through reproduction of parameters such as voltage, current, charging, discharging, load changes, state of charge (SOC), state of health (SOH), and fault conditions. Although simulation cannot replace every physical battery test, it provides an environment that is safe and repeatable for testing purposes.
